Durable and convenient high brightness waterproof outdoor LED rental display
Our waterproof outdoor rental LED display is designed for large, temporary events, with high brightness, quick assembly and disassembly, and intelligent screen. Whether it is a music festival, sports event or large stage, this display can provide a good display effect in any adverse weather conditions. It is easy to install and supports front and back maintenance.
Feature and Advantage





Specifications
|
LED outdoor rental screen RH-B series (hard connection) |
||||
|
Module model (mm) |
RH-B 2.6 |
RH-B 2.9 |
RH-B 3.9 |
RH-B 4.8 |
|
Module point spacing (mm) |
2.604 |
2.976 |
3.91 |
4.81 |
|
Module Size (mm) |
250x250 |
250x250 |
250x250 |
250x250 |
|
Module pixel |
96x96 |
84x84 |
64x64 |
52x52 |
|
Density pixels (dot/㎡) |
147456 |
112896 |
65536 |
43264 |
|
Lamp bead model |
SMD1415 |
SMD1415 |
SMD1921 |
SMD1921 |
|
Brightness (cd/㎡) |
≤4500 |
≤4500 |
≤4500 |
≤4500 |
|
Refresh rate (Hz) |
1920/3840 |
1920/3840 |
1920/3840 |
1920/3840 |
|
Scanning mode |
1/24sweep |
1/21sweep |
1/16sweep |
1/13sweep |
|
Box size (mm) |
500x1000 |
500x1000 |
500x1000 |
500x1000 |
|
500x1000 cabinet resolution |
192x384 |
168x336 |
128x256 |
104x208 |
|
Box size (mm) |
500x500 |
500x500 |
500x500 |
500x500 |
|
500x500 cabinet resolution |
192x192 |
168x168 |
128x128 |
104x104 |
|
Lamp bead working life |
≥100,000 hours |
|||
|
Pixel composition |
RGB three-in-one |
|||
|
Grayscale |
14bit |
|||
|
Maximum power (W/㎡) |
1000-1200W |
|||
|
Conventional power (W/㎡) |
400-600W |
|||
|
Eliminate ghosting |
equipped |
|||
|
input voltage |
AC100~240V 50/60HZ |
|||
|
Module input voltage |
DC4.7~5V±0.2V |
|||
|
Environment |
Temperature -10~40℃ Humidity 10%-90% |
|||
|
500x1000 box weight |
(Normal 13kg)/(Added arc lock box weight 13.5kg) |
|||
|
500x500 box weight |
(Normal 7.3kg)/(Added arc lock box weight 7.6kg) |
|||
Application Areas
Stage rental / Banquet hall / Conference / lecture hall / Exhibition display / Transportation / Entertainment culture /Sports venues.

Highmight Serve

1. Demand Analysis
Make the best solution based on the information provided by the customer or the model parameters specified by the customer.
2. Product Recommendation
Parameter Recommendation: Recommend screens with different dot pitches according to the customer's viewing distance to ensure appropriate resolution and clarity.
Brightness Recommendation: Outdoor activities usually require higher brightness to cope with strong natural light;
Installation Method: Recommend different installation methods (mounting, bracket installation, etc.) according to the on-site conditions, and provide necessary structural parts and accessories.
3. Product Display and Experience
Product Demonstration: Arrange product display and on-site experience for customers, demonstrate the effects, brightness, color, stability and other characteristics of the screen, so that customers can intuitively understand the display effect.
Sample Case Sharing: Show photos or videos of past successful cases to help customers refer to the actual use effects of similar activities.
4. Technical Support
Technical Solution Consultation: Provide technical consulting services to help customers understand the advantages and disadvantages of products of different specifications, and how to choose appropriate control systems and playback devices.
Installation Support: Provide installation accessories for LED display screens according to on-site conditions to ensure the stability and safety of installation.
5. After-sales guarantee plan description
Warranty and maintenance commitment: Explain the product warranty terms and service process, provide customers with maintenance service plans, and ensure that customers can use the equipment for a long time and stably.
About us
Highmight Factory is a leading manufacturing base in China's LED display industry, with the latest modern production facilities and automated equipment. With the continuous expansion of the company's scale and the improvement of production technology, the factory's production capacity has been steadily increasing every year. At present, the factory's monthly shipments can reach 500,000 modules, ensuring that it meets the growing needs of customers.
The factory has multiple specialized production lines, including the research and development, production, testing, assembly, quality inspection, etc. of LED display screens. The factory adopts industry-leading automated production technologies, such as fully automatic placement machines, reflow soldering equipment, precision dispensing machines, etc., which greatly improves production efficiency and product quality. In addition, the factory's R&D center is committed to product innovation, especially in the fields of LED rental display screens, outdoor high-brightness display screens, transparent LED display screens, etc. It is in an industry-leading position.
Highmight Factory strictly follows the ISO9001 quality management system. All products are strictly controlled and tested from raw material procurement to finished product delivery to ensure that the quality of each product meets industry standards and customer requirements.
Highmight Factory provides LED display products to countries around the world. In order to ensure that customers receive timely product and service support, the factory has established long-term cooperative relationships with many logistics companies to ensure that products can be delivered quickly and safely to all parts of the world. At the same time, the factory is equipped with a strong after-sales service team to provide technical support such as product installation, commissioning, and maintenance.


Certificate

FAQ
Q: How bright is the rental screen?
A: Outdoor screens are generally 4000-6000nits, and indoor screens are 800-1500nits to adapt to different ambient light.
Q: Can a rental screen be connected to multiple monitors?
A: Yes, rental screens can achieve multi-screen linkage display through splicing and control systems.
Q: Does the rental screen consume a lot of power?
A: The power consumption depends on the size of the screen, but compared with traditional LED displays, LED rental displays are more energy-efficient.
Q: How does a rental screen achieve high-definition display?
A: By choosing smaller dot pitch and higher refresh rate technology, the clarity and restoration of LED displays can reach a higher level.
Q: What is the refresh rate of a rental screen?
A: Generally between 1920Hz/3840Hz, and a higher refresh rate brings the screen effect to a higher level.
